General Details

Belt Feeder

Zhenyuan Company offers heavy-duty belt feeders that are capable of handling nearly any material. Belt feeders are used to provide a controlled discharge rate of material from a bin or hopper and introduce it into a process. Able to handle a variety of materials, belt feeders are reliable and useful in an endless amount of applications.

Comprised of a conveyor belt on rollers, belt feeders are available in a variety of sizes and capacities, based on the needs of your process and material.

belt feeder structureApplications:
  • Coal Handling for Power Plants
  • Clinker and other raw materials for Cement Plants
  • Woodchip and Bark Handling for Pulp/Paper Mills
  • Sludge Handling for Process Applications
  • Rail Unloading/Loadout
  • Granular Products
  • Sand
  • And more

1. Large capacity: 160~4400 t/h.

2. Working smoothly, doesn’t have phenomena of vibration, not easy to damage.

3. Low motor power, so it is energy saving and environment friendly products.

4. Use impact idler, reduce the cushion.

5. Can add weighing device, so it is also a weigh feeder.





send inquiry

If you have some questions about our products, please feel free to fill out the form below, and we will contact you within 24 hours. Rest assured that we won’t reveal your information to anyone.

Your Name (required)

Your Email (required)


Your Message


Technical Data
Belt Feeder Technical Data
Model Power(kw) Voltage(AC V) Speed Adjustment
Speed Scope Feeding Scope Weight
GLD800/5.5/S 5.5 AC380
Manual 0.4-0.7 160-800 3700
GLD800/5.5/B Auto 0.42-0.7 480-800 3800
GLD2000/5.5/S 5.5/7.5 Manual 0.6-0.1 400-2000 4200
GLD2000/5.5/S Auto 0.2-0.1 1200-2000 4300
GLD3300/5.5/S 7.5 Manual 0.2-0.1 660-3300 5200
GLD3300/5.5/S Auto 0.6-0.1 1980-3300 5300
GLD4400/5.5/S 11 Manual 0.3-1.5 880-4400 6200
GLD4400/5.5/S Auto 0.9-1.5 2640-4400 6300
More Pictures
armored belt feeder in site

belt feeder in site 1

belt feeder in site
